Mid Drive Motor QS165 5000W 90KPH Brushless PMSM Mid Drive Motor with V2 FarDriver Controller ND72450 N7 Display and T08(N7 Display-Rated 60V)

controller- Kit Including -1 pc x QS165 5KW Mid-drive motor (hall type)1 pc x Fardriver ND72450 with BT1 pc x N7 Display1 pc x T08 Throttle3) Rated Working Voltage Range: 48V-96V(Marked as 60V/72V)4) Speed: 6000-6500RPM(no load)5) Magnet Height: 35H 5 Pole pairs6) Max Torque: 50N.m7) Efficiency: 93%8) Peak Current Limit: 180A9) Peak Phase Current: 500A10) Working Temperature: 60 peak11) Single Hall Set with waterproof connector12) Waterproof Grade: IP6713) Cooling: Air cooling14) Phase wire: 16mm²- Fardriver Controller -2) Model Number: ND724503) Working Communication: Hall Sensor4) Peak DC Current: 200A5) Peak Phase Current: 450A6) Working Voltage: 48V/60V/72V max. 88V7) Available Motor Power: 3000W-5000W8) Case Material: Aluminum9) Size: 180mm * 118mm * 60mm10) Weight: 2.1KGS

• controller
• High torque output: amplified torque through gear reduction suitable for steep slopes mountains and other complex terrain
• Modularized design: motor controller and sensor are highly integrated and the parts can be replaced separately during maintenance.
• Compatible with a wide range of vehicles: can match vehicles with different wheel diameters and tire types.
• High stability: The motor is located in the middle of the vehicle to improve driving stability especially suitable for high-speed riding or off-road scenarios.
• Wide applicability：It is suitable for DIY electric scooters electric bikes E-Motorcycle Moped etc.
