12 inch Bathroom Exhaust Fan Wall Exhaust Fan 989 CFM Inline Cooling Vent Big Airflow Blower Window Ventilator Thick Power Cord for House Kitchen Attics Garage Basement Home Workshops (White )

Parameters: 12 inch Power: 120W Hole Size: 300mm Air Volume: 1680m3/h Frequency: 50Hz Voltage: 110-240V Rotating Speed: 2800r/min Feature: Modern design and good looking. Fan e and blade are made of high-quality ABS plastic, UV resistant. Fan with reliable low-watt motor, continuous operation. Protection class: IPX2 Mounting: The fans are directly mounted into the ventilation shaft. In case of remote location of ventilation shaft, connect a flexible air duct to the fan with a clamp. Fix the fan to wall by self-tapping screws. Suitable for ceiling mounting. Application: Continuous or periodic exhaust ventilation area such as bathroom, showers, kitchens and other spaces. Installation Method: 1. Glass wall mounting Install the bathroom exhaust fan on the glass wall, without screws you can just use some glue to fix him in the glass holes you have reserved, this should be the easiest way to install it, remember not to forget to reserve the position of the wires. 2. Normal wall mounting You will need to drill holes in the wall where the screw holes for the exhaust fan are located to fix it, the panel and install the exhaust fan to your exhaust duct remembering to connect the wires first. Tighten the screws to cover the panel and you're done. 3. Ceiling mounting The same installation is done on the ceiling but you must remember that ceiling mounted exhaust fans must have the non-return valves d as they cannot be deployed this could burn out the motor!

• IDEAL VENTILATION HOUSEHOLD KIT: Equipped with 7 fan blades and square grille, wall-mounted fan can be installed on grass or window to keep duct, odor away from you. And the light indicator can show you working status when power on or off.
• HIGH-RUNNING SPEED POLE BEARING MOTOR: Window vent fan motor uses sealed pure copper bearing with lubrication and over heating protection, It moves smoothly to provide continuous air flow with lower noise and protect device if under improper cooperation.
• THICK INLINE AIR BOOSTER: With only 235mm inline length, window extractor can fit well through the wall. It's a good construction for attic, office, home, HVAC system such as grow tent.
• WIDELY USE & EASY INSTALLATION: You can use our home ventilation fan easily to keep cooking smoke out of kitchen or humidity away from bathroom such suitable place that required ventilation.
• POWERFUL&ENERGY SAVING: 120W power, 110V-240V and 50-60Hz, the rated speed of 12 inch ventilation air booster is up to 2800r/min with big air value 1680 m3/h( 989CFM). You can enjoy fresh air by opening it.
